• img_013hh8We are glad to present a new series of fire-resist glass «ProFire» (EI-30, EI-45, EI-60) which has developed by Sacura Group in 2007.

    General information

    Fire-resistant glass ProFire consists of 2 float glass sheets with a polymer composition between them.

    Under standard fire conditions the glass ProFire ensures the fire-resistance limits of ЕI-15, ЕI-30, ЕI-45 and ЕI-60

    The fire-resistant glass “ProFire” have good optical quality and high using

    characteristics:

    • Improved optical transmission factor (to 0.85)
    • Invariability of characteristics under UV-radiation
    • Average weight is 30% lower than existing analogues
    • Minimum quantity of optical defects and distortions
    • Heat insulation and sound proofing
    • Safety and durability.
    • Expanded temperature range (from -40°С to +80°С)

    Quantity

    The quantity and the fire-resist characteristics of the glass ProFire are supervised during every step of production according to the ISO 9001:2001.

    Fire-resist requirements

    The glass ProFire were tested in the steel and aluminum fire-resist constructions (single and double-doors and fire-resistant dividing walls) for the accordance of the Ukrainian fire-resist standards which had harmonized with EN 1363 and EN 13501-1 on the Integrity and insulation criteria.

    Sphere of application

    The glass ProFire can be used in the following variants:

    - in the internal and external constructions without the additional UV-filters and also in multiple-glass window;

    - in addition to the against-breaking, impact-resistant and bullet-resistant constructions;

    - in combination with glass decorative constructions: tinted glass, frosted glass, the glass with decorative design etc;

    The maximum size of tested glass is 1200х2500 mm.

    The glass delivery could be executed in the sheets of 1600х2200mm, which should be cutting in place, as well as in the final size products.

    TECHNICAL CHARACTERISTICS for ProFire

    Fire-resist limit

    Thickness,

    mm

    Weight 1sq.m./kg

    «ProFire» ЕI-15

    11

    25

    «ProFire» ЕI-30

    17

    31

    «ProFire» ЕI-45

    21

    36

    «ProFire» ЕI-60

    25

    41

    profire 001 profire 008 profire 005
